Software 232 / BMW bike / handsfree key unit ZADI

Memory device is INFINEON TRICORE TC233-32.
You can read INFINEON TRICORE TC233-32 with VVDIProg. (Connection diagram below)
Expected file size is 131072 bytes.
Software can program:
– UNLOCKED BMW handsfree key.
– Texas Crypto 128-bit AES transponder.
Written handsfree key or transponder are ready programmed to start bike.
IMPORTANT NOTE: in case you use transponder you must place it close to antenna for to start bike. In case you use handsfree key you must place it close to antenna for to activate it. (Different antenna locations below)
Vehicles equipped with this unit:
BMW: R1300GS

Different antenna locations:

Connection diagram:
