Software 163 / Suzuki / engine ECU with ID46

Memory device is serial eeprom 93c56 or 93c66 both SMD8 package.
For 93c56 expected file size is 256 bytes, for 93c66 is 512 bytes.
Use Philips PCF7936 – Silca T14 – JMA TP12 or CN3 transponder.
The written transponder is ready and programmed to start the vehicle.

Vehicles equipped with this unit:
Suzuki: Swift(2007-), Splash(2007-), Grand Vitara(2007-)
Fiat: Sedici
