Software 130 / BMW, Mini / CAS SiemensVDO
Memory device is Motorola MCU 912DG256 or 9S12DG256 or 9S12XDP512
The expected file size is 2048 or 4096 bytes.
IMPORTANT NOTE: Motorola MCU is locked, not possible to read/write with TMPro.
If the job isย ALL KEYS LOSTย and you get the message thatย file is CAS3+:
โ ifย ISN is 16 bytesย you needย EEPROM file read from engine ECU.
โ ifย ISN is 2 bytesย it is not possible to make key with TMPro.
If the job isย SPARE KEYย โ in all cases you need just CAS file.
For ECU with MPC556 MCU you must read external EEPROM 95c640.
For ECU with TRICORE MCU you must read EEPROM from TRICORE.
Use PCF7936 transponder or remote key.
Written transponder or remote key is ready programmed to start car.
To activate the remote: insert the key to turn the ignition ON. Remove key. Press any button a few times. Repeat these steps till the remote starts to work.
If you have got locked CHINESE BMW HITAG2 remote keys, you canย UNLOCKย them and set asย BRAND NEWย so you can use them again with any car.
Vehicles equipped with this unit:
BMW: series 1, series 3, series 5, series 6, X-3, X-5, X-6
Mini: Cooper
Software 130 / BMW, Mini / CAS SiemensVDO
Memory device is Motorola MCU 912DG256 or 9S12DG256 or 9S12XDP512
The expected file size is 2048 or 4096 bytes.
IMPORTANT NOTE: Motorola MCU is locked, not possible to read/write with TMPro.
If the job isย ALL KEYS LOSTย and you get the message thatย file is CAS3+:
โ ifย ISN is 16 bytesย you needย EEPROM file read from engine ECU.
โ ifย ISN is 2 bytesย it is not possible to make key with TMPro.
If the job isย SPARE KEYย โ in all cases you need just CAS file.
For ECU with MPC556 MCU you must read external EEPROM 95c640.
For ECU with TRICORE MCU you must read EEPROM from TRICORE.
Use PCF7936 transponder or remote key.
Written transponder or remote key is ready programmed to start car.
To activate the remote: insert the key to turn the ignition ON. Remove key. Press any button a few times. Repeat these steps till the remote starts to work.
If you have got locked CHINESE BMW HITAG2 remote keys, you canย UNLOCKย them and set asย BRAND NEWย so you can use them again with any car.
Vehicles equipped with this unit:
BMW: series 1, series 3, series 5, series 6, X-3, X-5, X-6
Mini: Cooper
ืืืืข ืขื ืืืืฆืจ
ืืืืข ืขื ืืืืฆืจ
ืืฉืืื ืืืืืจืืช
ืืฉืืื ืืืืืจืืช
Description
Memory device is Motorola MCU 912DG256 or 9S12DG256 or 9S12XDP512
The expected file size is 2048 or 4096 bytes.
IMPORTANT NOTE: Motorola MCU is locked, not possible to read/write with TMPro.
If the job isย ALL KEYS LOSTย and you get the message thatย file is CAS3+:
โ ifย ISN is 16 bytesย you needย EEPROM file read from engine ECU.
โ ifย ISN is 2 bytesย it is not possible to make key with TMPro.
If the job isย SPARE KEYย โ in all cases you need just CAS file.
For ECU with MPC556 MCU you must read external EEPROM 95c640.
For ECU with TRICORE MCU you must read EEPROM from TRICORE.
Use PCF7936 transponder or remote key.
Written transponder or remote key is ready programmed to start car.
To activate the remote: insert the key to turn the ignition ON. Remove key. Press any button a few times. Repeat these steps till the remote starts to work.
If you have got locked CHINESE BMW HITAG2 remote keys, you canย UNLOCKย them and set asย BRAND NEWย so you can use them again with any car.
Vehicles equipped with this unit:
BMW: series 1, series 3, series 5, series 6, X-3, X-5, X-6
Mini: Cooper
